UC202-10-BLK Oxide Plated Plated Insert 5/8 Bore Bearing
$36.99
SKU: Kit15339
UPC: 00193019220993
UPC: 00193019220993
Item: UC202-10-BLK Bearing
Type: Oxide Plated Insert Ball Bearing
Shaft Diameter: 5/8" inch
Dynamic load rating: 12800 N
Static load rating: 6272 N
Type: Oxide Plated Insert Ball Bearing
Shaft Diameter: 5/8" inch
Dynamic load rating: 12800 N
Static load rating: 6272 N
|
UC202-10-BLK Oxide Plated Insert Ball Bearing 5/8" inch Inner Diameter |
|
UC202-10-BLK Oxide Plated Insert Ball Bearing, bearing is wide inner ring with spherical outer ring, bearing ihasrelubrication groove with oil hole on set screw side, bearing is anti-rotation pin on side opposite grease groove, bearing is nylon patched class 3A set screws. Black oxide has certain properties and characteristics that makes it ideal for certain applications. It is used to add corrosion resistance and for appearance
|
| Dimensions (inches) | ||||||||
|---|---|---|---|---|---|---|---|---|
| D | Bi | Be | r | n | m | G | W | ds(Unf-Thread) |
| 1-55/64" | 1-7/32" | 19/32" | 0.039" | 1/2" | 23/32" | 0.197" | 1-1/8" | 1/4-28x1/4 |
