Two Wheel Strut Channel Trolley Rollers For Use With 1 And 5 Eighths Inch Wide And Taller Strut Channel Heavy Duty Rubber Sealed Bearing Trolley Assembly High Load Capacity Up To 810 Lbs At 400 RPM And 3245 Lb Ultimate Break Strength

Heavy-Duty 2-Wheel Strut Trolley for 1-5/8 Channel
✔️ Single-pack trolley for 1-5/8 in wide channel (41.3 mm), 810 lb

This 2-wheel trolley assembly is built for use with 1-5/8 inch wide strut channel and taller variants. It features galvanized solid steel construction, rubber-sealed low-speed bearings for grease maintenance, and a durable top that accommodates screw heads up to 0.5"W x 0.2"H. Common applications include sliding doors, electric hoists, small elevators, heavy curtains, and other load-moving setups in industrial and workshop environments.

✅ 300 RPM rated load: 220 lbs (100 kg)
✅ 400 RPM rated load: 810 lbs (368 kg)
✅ 50 RPM rated load: 630 lbs (286 kg)
✅ 25 RPM rated load: 780 lbs (354 kg)
✅ Ultimate break strength: 3245 lbs (1472 kg)

💡 What is a strut channel trolley roller used for in heavy-duty linear motion systems? This handy component helps move loads along guided rails. - High-load performance along 1-5/8" channel - Compatible with taller channels for varied heights - Rubber-sealed bearings enable grease maintenance for longer life - Ideal for sliding doors, hoists, curtains and other load-moving tasks
