Two Pack 90 Degree Push To Connect Fittings For Pneumatic Systems One Eighth Inch NPT Female Tube OD 0.39 Inch Nickel Plated Brass Quick Connect Elbow Adapters For Air Lines Blue

Two-Pack 90° Push-To-Connect Pneumatic Elbows
✔️ Nickel plated brass, blue 1/8 in NPT female, 10 mm tube OD

These 90-degree push-to-connect fittings are designed for pneumatic systems, offering fast, tool-free tube insertion and leak-tight performance. The click-lock mechanism secures tubing reliably under pressure, while a robust plastic housing provides corrosion resistance for long service life. Widely used in factory air circuits, compressor lines, laser equipment linkage, automated production lines, and high-pressure air testing.

✅ Thread size: 1/8 in NPT female
✅ Tube OD fit: 10 mm / 0.39 in
✅ Outer diameter: 17.5 mm / 0.69 in
✅ Size (L x W): 37 x 32.5 mm / 1.46 x 1.28 in
✅ Hex size: 17 mm
✅ Material: Nickel plated brass, plastic
✅ Color: Blue
✅ Pack: 2 pieces

💡 What is a push-to-connect pneumatic elbow used for in industrial air systems?

It provides a handy, quick-connect solution for routing compressed air with directional changes in production lines.

- push-to-connect design for fast assembly in pneumatic systems - 1/8 in NPT female thread compatibility with standard ports - 10 mm (0.39 in) tube OD fitting for many air lines - corrosion-resistant nickel-plated brass housing for durability ✝️
