VXB

TK20-OP Self Aligning Ball Bushings 20 mm Linear Motion

$48.99
SKU: TK20OP
UPC: 00193019063620
Item: TK20-OP Ball Bearing
Type: Linear Motion Ball Bushing
Ball circuit: 6
Size: 20 x 32 x 45 mm
Bearing Inner Diameter: 20 mm
TK20-OP:TopBall
High Load Standard type: Linear Systems
Self Aligning Ball Bushing


TK20-OP 20 Bore High Load Standard type TopBall metric type linear motion ball bushings/bearings inner diameter(bore) is 20 mm dimensions with built-in seals the Top ball slide bush is a high performance bushing with three times the load capacity capable of providing up to 27 times normal travel life of a conventional slide bushing high accuracy grade linear bushings series mainly used in the USA.

  • Item: TK20-OP Ball Bearing
  • Type: Linear Motion Ball Bushing
  • Ball circuit: 6
  • Size: 20 x 32 x 45 mm
  • Bearing Inner Diameter: 20 mm
  • Bearing Outer Diameter: 32 mm
  • Bearing Length: 45 mm
  • Dynamic Load Rating: 2090 N
  • Static Load Rating: 2630 N
  • Quantity: One Bearing
