Tie-Rod Pneumatic Air Cylinder With 32mm Bore And 600mm Stroke PT One-Eighth Port Double Acting Self-Lubricating Actuator For Heavy-Duty Industrial Automation And Woodworking Equipment With Adjustable Cushion

32mm Bore Pneumatic Cylinder, 600mm Stroke, Single Unit
✔️ Double-acting, PT 1/8 port, 1.0-9.0 bar, self-lubricating

Heavy-duty tie-rod pneumatic actuator designed for industrial automation and woodworking equipment. It provides reliable push and pull power with a long service life, and it fits standard 32mm cylinder frames as a drop-in replacement.

✅ Bore: 32mm (1.25"), Stroke: 600mm (23.62"), Port: PT 1/8, Double Acting, Air
✅ Pressure: 1.0-9.0 bar (14.5-130 psi), Speed: 50-800 mm/s
✅ Body: aluminum alloy, piston rod: hard-chromium plated steel, seals: NBR
✅ Cushion: adjustable terminal cushioning; Temperature: -5 to 70°C; Self-lubricating

💡 What is a pneumatic double-acting cylinder with adjustable cushion used for in heavy-duty automation?

In short, this handy actuator offers precise, smooth motion and long life in tough environments.

- Handy for repetitive push/pull cycles in automation
- Self-lubricating seals minimize downtime
- 32mm bore and 600mm stroke fit standard frames
- PT 1/8 port and adjustable cushion boost control
