Three Phase General Purpose Pump Motor Half Horsepower 56J Frame 208 To 230 And 460 Volt AC Bearing Protection Shaft Shields Continuous Duty 60 Hz Workhorse Build 8.5 Inch Length 6.44 Inch Height Insulation Class B
✔️ 60 Hz 3-Phase, 208-230/460 V, open drip-proof, continuous duty, pack 1
General purpose pump motor designed for continuous duty and used in water pumps, irrigation, and small industrial circulating systems. It features bearing protection shaft shields and a sturdy steel frame for reliable performance across common pumping tasks.
✅ Frame 56J, 1/2 HP, 3-phase, 60 Hz, 208-230/460 V
✅ Open drip-proof enclosure, steel frame, standard efficiency
✅ Bearing protection with shaft shields and ball bearings
✅ Continuous duty, max ambient 104 °F, insulation class B
✅ Body dia 6.4 in (162.56 mm), bolt circle dia 5 7/8 in (149.23 mm)
✅ Length without shaft 8.5 in (215.90 mm), height 6 7/16 in (163.51 mm)
| Dimension | In | mm |
| Body Dia. | 6.4 in | 162.56 mm |
| Bolt Circle Dia. | 5 7/8 in | 149.23 mm |
| Height | 6 7/16 in | 163.51 mm |
| Length (Less Shaft) | 8 1/2 in | 215.90 mm |
✅ Frame 56J, 1/2 HP, 3-phase, 60 Hz, 208-230/460 V
✅ Open drip-proof enclosure, steel frame, standard efficiency
✅ Bearing protection with shaft shields and ball bearings
✅ Continuous duty, max ambient 104 °F, insulation class B
✅ Body dia 6.4 in (162.56 mm), bolt circle dia 5 7/8 in (149.23 mm)
✅ Length without shaft 8.5 in (215.90 mm), height 6 7/16 in (163.51 mm)
💡 What is a general purpose three-phase pump motor used for in industry?
This handy motor handles typical pumping duties across water, irrigation, and HVAC systems.
- Useful for water transfer and circulating pumps in commercial buildings
- Operates on 208-230/460 V, 60 Hz, 3-phase
- 56J frame fits standard mounting bases and bases
- Shielded bearing protection helps extend service life in tough environments
