Pro Grade Half Bridge Strain Gauge Sensor For Torque And Shear Force, Wheatstone Bridge Rosette, Resistance Type 120/350/1000 Ohms, BF1K-2/3/4HA Series, Imported Constantan Gauge Element, Novolac Epoxy Base, High Sensitivity And Low Heat Output

Pro Grade Half-Bridge Strain Gauge for Torque and Shear
✔️ BF120/350/1K-2/3/4HA, Novolac epoxy base, imported constantan

This sensor is a half-bridge strain gauge designed to measure torque and shear forces in mechanical rigs, test fixtures, and precision instrumentation. It uses a Wheatstone bridge rosette configuration with a constantan gauge element and a Novolac epoxy base for stable readings at room temperature.

✅ BF120/350/1K-2/3/4HA Half-bridge strain gauge resistance types 120/350/1000 ohm
✅ Heat output coefficient <2 um/m/℃
✅ Dispersion to average heat output <30±um/m
✅ Base material Novolac-epoxy
✅ Sensitive gate material Imported constantan
✅ Room temperature insulation resistance 10000 mohm
✅ Room temperature strain limit 20000 um/m
✅ Mechanical lag 1.2 um/m

💡 What is a half-bridge strain gauge used for in torque and shear force sensing applications?

This handy sensor helps measure changes in strain from torque and shear in mechanical systems.

- Handy torque measurement in motors, machines, and test rigs - Handy shear force sensing in structural components - Wheatstone bridge rosette compatibility for precise readings - Low heat output helps maintain stable data ✝️
