Premium Benchtop Arbor Press Featuring Smooth Manual Lever Operation Ideal For Riveting Bending Punching And Metal Fabrication Straight Up Reliable Shop Workhorse Built Tough To Handle Every Badass Project Without Missing A Beat
✔️ 1 Ton Rating 25:1 Leverage Ratio Cast Iron Frame Max Opening 36mm
This single benchtop arbor press provides the leverage needed for riveting, punching, squeezing parts, and bearing installation on your workbench. You can mount this unit to a sturdy table using the four pre-drilled countersunk holes in the base, keeping operations stable while you use the hand crank to apply pressure through the smooth pinion drive onto the steel ram and anvil.
✅ Overall size measures 5.5W x 8.5D x 21H inches 139.7 x 215.9 x 533.4mm height excludes handle✅ Rated at one ton capacity with a 25:1 gear ratio multiplying manual effort for serious pressing power
✅ Features a steel ram guided by a pinion drive and a flat steel anvil for precise alignment
✅ Maximum opening measures 36mm 1.42 inches while the powder-coated cast iron body keeps things steady
✅ Package includes one arbor press unit with pre-drilled mounting holes for secure table attachment
💡 What are the benefits of using a manual arbor press for shop maintenance?
A manual arbor press multiplies your physical effort through gearing while keeping force directed straight down, making it a handy fixture for repetitive tasks.
- The 25:1 gear ratio lets you crank easy pressure into massive output force for tackling stubborn bearings or tight press-fit joints.
- The steel ram slides on guides for perfect vertical tracking so bushings go in square and pins land centered without wobble.
- Bolted mounting stops the base from walking around when you apply torque, giving you a rock-solid stage for riveting or bending work.
- Steady leverage reduces finger strain compared to sledgehammers while delivering repeatable results across hundreds of cycles.
