Planetary Gearbox Speed Reducer Ten To One Reduction With Low Backlash Of 12 Arc Minutes 3000 RPM Max 14 Mm Input Bore And 14 Mm Output Shaft 60 By 130 Mm Frame 95 Percent Full Load Efficiency Great For CNC Routers And 60 Mm Servo Motors
✔️ Backlash ≤12 arc-min - 95% full-load efficiency - 3000 rpm input speed
This single-unit planetary gearbox speed reducer is built for CNC routers, engraving machines, lathes, and 3D printers. It provides a 10:1 reduction with low backlash and 95% full-load efficiency, using a 60 x 130 mm aluminum housing and 14 mm input/output bores. Includes 4 x M4 screws and a key block for secure mounting.
✅ Reduction ratio: 10:1
✅ Backlash: ≤12 arc-min
✅ Frame size: 60 x 130 mm / 2.362 x 5.118 in
✅ Body length: 78 mm / 3.071 in
✅ Input bore: 14 mm / 0.551 in
✅ Output shaft: 14 mm / 0.551 in
✅ Full-load efficiency: 95%
✅ Rated input speed: 3000 rpm
✅ Max input speed: 5000 rpm
✅ Package content: 1 Pcs x Planetary Reducer for 60mm Servo Motor with 4 x M4 screws, 1 x key block
💡 What is a planetary gearbox used for in CNC machines and automation systems?
A handy overview to help you decide if it's the right fit for your setup:
- high torque at low speeds for precise control in CNC routers and servo-driven machines- handy for compact installations with 60 mm servo motors and limited space
- low backlash and smooth torque transmission improve positioning accuracy
- efficient power transfer and long life in harsh industrial environments
✝️
