NBK Japan MJC-14-WH 1/8" inch to 6mm Jaw-type Flexible Coupling

NBK Japan MJC-14-WH Jaw-Type Flexible Coupling 1/8" to 6mm, Stainless Steel, Zero-Backlash, Made in Japan - high-precision shaft connector for motors, CNC, and robotics
✔️ 1/8 in (3.175 mm) to 6 mm bore, 14 mm OD (0.551 in), 22 mm length (0.866 in), stainless steel, zero-backlash at low torque, electrical insulation, Made in Japan

NBK Japan MJC-14-WH is a jaw-type flexible coupling designed to connect two shafts with tolerance for slight misalignment and end-play. It’s commonly used in motor drives, CNC machines, and robotics where precise torque transfer and insulation are important. This single-piece unit is made in Japan from stainless steel, offering strong durability and a clean, reliable connection.

✅ Bore 1: 1/8 in (3.175 mm)
✅ Bore 2: 6 mm (0.236 in)
✅ Length: 22 mm (0.866 in)
✅ Outer diameter: 14 mm (0.551 in)
✅ Material: Stainless steel
✅ Torque: 0.7 N·m
✅ Wrench size: M3
✅ Pack size: 1 piece
✅ Made in Japan
💡 What is a jaw-type flexible coupling used for in precision shaft connections? Jaw-type flexible couplings join shafts with tolerance for misalignment and end-play, enabling smooth, backlash-minimized torque transfer. - handy for servo motors, CNC drives, and robotics - accommodates eccentricity and angular misalignment under load - provides electrical insulation and durable stainless steel construction This handy coupling helps maintain alignment and reduce vibration in everyday drive applications
