Nachi

N326 Nachi Bearings Steel Cage Japan 130x280x58 Large Bearings

$1,937.99
SKU: Kit10328
UPC: 00193019087886
Item: N326 Roller Bearing
Type: Nachi Cylindrical Roller Bearing
Cage: Steel Cage
Dimensions: 130mm x 280mm x 58mm/Metric
ID (inner diameter)/Bore: 130mm
N326 Nachi Cylindrical Roller Bearing
Steel Cage
130mm x 280mm x 58mm
Made in Japan


N326 Nachi Cylindrical Roller Bearing, Steel Cage, Made in Japan, the N326 inner diameter is 130mm, the N326 outer diameter is 280mm and the N326 width is 58mm.

  • Item: N326 Roller Bearing
  • Type: Nachi Cylindrical Roller Bearing
  • Cage: Steel Cage
  • Dimensions: 130mm x 280mm x 58mm/Metric
  • ID (inner diameter)/Bore: 130mm
  • OD (outer diameter): 280mm
  • Width/Height/thickness: 58mm
  • Size: 130 x 280 x 58 mm
  • Quantity: One Bearing
  • Dynamic load rating Cr: 555,000 N
  • Static load rating Cor: 665,000 N
  • Limiting Speed:
    • Grease Lubrication: 2,200 RPM
    • Oil Lubrication: 2,600 RPM
  • Made in Japan

Construction of this roller bearing type is the simplest of all radial roller bearings. This bearing type is often used in high-speed applications. Because the inner ring, outer ring, and rollers are in line contact, this bearing type has a large radial load capacity. Various Cylindrical roller bearing configurations are:N,NJ,NF,NU,RNU : integral ribs (flanges)
NH,NP,NUP,NUH : integral and loose ribs
NN,NNU : double-row bearings
Configurations having integral flanges or loose ribs on both the inner and outer rings can sustain a small amount of axial load. Since this bearing type supports axial loads as sliding action between the end of the rollers and flange faces, axial loading is limited. Double-row Cylindrical roller bearings are used for high-speed, high-accuracy applications such as; main spindle support for lathes, milling machines, and machining centers. Radial clearance of tapered-bore bearings can be adjusted during mounting of the bearing(s) onto the mating journal. Standard cages are pressed steel or polyamide resin. Machined cages of high-strength brass are used for bearings of large dimension or for high-speed applications.
