MBT One Drop-In Style Machined Mounted Ball Transfer, Carbon Steel, One Inch Diameter, Two Hundred Pound Load Capacity, Fits One And Three Quarter Inch Hole, Case Of Ten, Heavy Duty Inline Material Handling
✔️ Premium drop-in ball transfer fits 1-3/4 in hole; 200 lb load cap
Drop-in mounted ball transfer unit built for carbon steel handling setups. It drops into a 1-3/4 inch hole and features a 1 inch main ball supported by 1/8 inch balls for smooth, low-friction movement. This heavy-duty inline component is a solid choice for factory benches, conveyers, and workstations where steady load transfer matters.
| Ball diameter | 1 in (25.4 mm) |
| Hole compatibility | 1-3/4 in (44.45 mm) |
| Load capacity | 200 lb (90.7 kg) |
| Material | Carbon steel |
| Finish | Hardened and plated ball cup; plated cover |
✅ Drop-in flange fits 1-3/4 in hole
✅ 1 in main ball rotates on 1/8 in support balls
✅ Ball cup machined from solid carbon steel; hardened and plated
✅ Plated steel cover
✅ Sealed and lubricated carbon steel housing for max life
✅ Load capacity 200 lb
✅ Case of Ten units
💡 What is a drop-in ball transfer used for in material handling? Drop-in ball transfers are handy for moving loads smoothly on conveyors and work surfaces. - Handy for pallet movements on assembly lines - Improves transfer between stations with less manual handling - Great for temporary fixtures that need quick setup
