High Precision Three And Six Axis Load Cell With Multi Axis Force Torque Sensor For Industrial Grade Robotics And Automation IP65 Rated Protection Built For Precision Machining And 0 To 50 Kg Applications

High-precision 3/6-axis load cell for robotics, 50 kg
✔️ IP65 sealed 3/6-axis load cell for precision robotics, single unit

This compact, high-precision multi-axis load cell provides accurate static torque measurements for automation, robotics, and precision machining, especially in fixed-position or non-continuous rotation setups.

✅ Range: 1, 2, 3, 5, 6, 10, 20, 30, 50, 100 kg
✅ Comprehensive error: ±0.1%, ±0.3% F.S
✅ Sensitivity: 1.5±10% mV/V
✅ Zero balance: ±2.0% F.S
✅ Non-linearity: 0.1-0.3% F.S
✅ Hysteresis: ±0.05% F.S
✅ Repeatability: ±0.05% F.S
✅ Creep: ±0.03% F.S/30min
✅ Temp.effect on span: ±0.05% F.S/10
✅ Temp.effect on zero: ±0.05% F.S/10
✅ Input resistance: 410±20
✅ Output resistance: 350±10
✅ Insulation resistance: 5000MΩ/100VDC
✅ Excitation voltage: 9-15VDC
✅ Compensated temp range: -10~60°C
✅ Operating temp range: -20~80°C
✅ Safe overload: 120% F.S
✅ Ultimate overload: 150% F.S
✅ Electrical connections: RED/E+, BLACK/E-, GREEN/S+, WHITE/S-
✅ Color: 0-50kg

💡 What is a multi-axis load cell used for in precision automation?

These handy sensors deliver real-time force and torque data for robotics and automation with practical benefits. - Measures multi-axis forces and torques - Provides static torque data for alignment and calibration - IP65 enclosure protects against dust and moisture - Improves control, repeatability, and safety in machining
