High Precision Single Point LiDAR Sensor With 0.1-12m Range And CAN Version For Drone Obstacle Avoidance Plug-and-Play Compatible With Pixhawk Arduino And Raspberry Pi 7-30V Wide Input With Reverse Protection Great For Robots And Drones

High-Precision LiDAR Sensor for Drones and Robots
✔️ TFmini-i CAN version, 0.1-12 m range, 1000 Hz, 52 g (1 pc)

This high-precision TFmini-i LiDAR module delivers reliable single-point distance sensing for drones, robots, and automated systems. Its CAN version makes it easy to integrate with Pixhawk, Arduino, and Raspberry Pi. The module supports a wide input range of 7-30 V with reverse polarity protection, and is supplied as a single unit per pack.

✅ Range: 0.1-12 m; accuracy 6 cm @ 0.1-6 m, and 1% @ 6-12 m
✅ Frame rate: up to 1000 Hz; typical 100 Hz
✅ FOV: 2 degrees; ambient light immunity 70 Klux
✅ Interface: CAN bus; 7-30 V input with reverse protection
✅ Size/Weight: 50 mm x 34 mm x 41 mm (1.97 x 1.34 x 1.61 in); 52 g
✅ Operating temp: -20 C to 60 C

💡 What is a common question about lidar distance sensors used in drones and robotics?

• Handy for obstacle detection and altitude hold to enable safer autonomous flights
• CAN interface simplifies integration with flight controllers like Pixhawk
• Wide input 7-30 V supports various power setups on different platforms
• High update rates ensure responsive obstacle avoidance in dynamic scenes
