Heavy Duty Workhorse General Purpose Electric Motor 2HP 3600RPM 575V 3 Phase 60Hz ODP Enclosure 145T Frame Premium Rolled Steel IP23 Class F 1.15 Service Factor NEMA Design B for Compressors Pumps Conveyors Fans
✔️ 575V 3-Phase, 60 Hz, NEMA B, SF 1.15, IP23, single unit ODP
This heavy duty general purpose electric motor powers compressors, pumps, conveyors, fans and other machinery in clean, dry industrial spaces. It features a 145T frame, ODP enclosure, IP23 protection, Class F insulation, and a 1.15 service factor, designed for inverter-friendly operation at multiple voltages.
✅ 2HP, 3600RPM, 575V, 3-Phase, 60Hz, 145T frame, ODP enclosure
✅ NEMA Design B, SF 1.15, for reliable loads
✅ Premium rolled steel housing with enamel coated corona resistant magnet wire
✅ IP23, Class F insulation, inverter duty for 230/460/575V
✅ Grounding terminal inside conduit box and drain plugs at ends
✅ 3 year warranty from fabrication date
💡 What is a heavy duty general purpose motor used for in large 575V 3-phase industrial setups? This handy motor drives compressors, pumps, conveyors, and fans in clean, dry environments. - 575V 3-phase, 60 Hz operation, 2HP output - NEMA Design B with 1.15 service factor for steady loads - IP23 enclosure and Class F insulation for inverter duty and rugged service
✝️
