Heavy Duty Three Quarter Inch Cast Aluminum Block Pulley For Rigging, 8,800 Lb Working Load, Large Block With Wide Sheave, Protective Side Plates, Built For Tough Hoists And Big Rigging Jobs

Single-block heavy-duty 3/4 in aluminum block pulley
✔️ 8,800 lb WLL, 4-5/8" wide sheave, 3/4" rope capacity

This heavy-duty block pulley is built for large rigging jobs and is commonly used in construction and industrial hoisting to guide and protect rope under heavy loads. It uses a thick aluminum alloy body, broad side plates to protect running ropes, and a wide 4-5/8" (117 mm) sheave to minimize bend. CE approved and engineered with stainless-steel axles for durability.

✅ WLL: 8,800 lbf (40 kN) CE Approved
✅ MBS: 200 kN (45,000 lbf)
✅ Sheave: 4-5/8" (117 mm); rope capacity: 3/4" (19 mm)
✅ Weight: 7.6 lb (3.45 kg); solid aluminum cheeks, stainless axles
✅ Broad side plates protect rope; green color for quick ID

💡 What is a block pulley used for in hoisting and rigging?

- Changes rope direction and supports loads in lifts - Reduces rope wear with a wide, protected sheave and side plates - Aluminum body with stainless axles for durability without excessive weight ✝️
