Heavy Duty 175 Ton Bow Shackles With Safety Bolt Built From Grade Eight Steel Quenched And Tempered Hot Dip Galvanized Finish Meets US RR C 271 Type IVA Class Three Five Times WLL Safety Factor For Maximum Rig Load
✔️ Pack: 1, MBL 5x WLL, Grade 8, quenched and tempered heavy duty
Heavy duty bow shackle rated at 175 tons, built from Grade 8 steel and quenched and tempered, with a hot-dip galvanized finish for corrosion resistance. This shackle is designed to connect steel wire rope, chain, and other rigging fittings in lifting and static systems, making it ideal for high-load industrial applications.
✅ Material: bow and pin high tensile steel, Grade 8, quenched and tempered
✅ Safety factor: MBL = 5 x WLL
✅ Finish: hot-dip galvanized; 175 ton size may be painted
✅ Temperature range: -20°C to +200°C
✅ Standard: meets US RR-C-271 Type IVA Class 3, Grade B
✅ Application: lifting and static systems with removable links
💡 What is a heavy duty bow shackle used for in lifting and rigging setups? This handy hardware helps connect lines in demanding jobs. - Handy for secure, high-load link connections in cranes and lifting systems - Great for permanent or semi-permanent installations where loads may shift - Prevents pin rotation and accidental uncoupling with a safety bolt design - Works with wire rope, chain, and other fittings in heavy industry
