Bearing Adapter Sleeve With Lock Nut And Washer For Tapered Bore Bearings, 60 mm Shaft Diameter, 65 mm Sleeve Bore, Thread M60x2, Width About 45 Mm, Includes KM13 Lock Nut And MB13 Lock Washer For Secure Mounting

Adapter Sleeve with Lock Nut & Washer for 60 mm Shaft (1 pc)
✔️ 60 mm shaft, M60×2 thread, KM13 lock nut, width ~45 mm

This adapter sleeve is designed to mount tapered bore bearings onto cylindrical shafts, typically in plummer block housings such as SNL513. It provides secure alignment and straightforward replacement in rotating assemblies.

✅ 60 mm shaft diameter
✅ Bore diameter 65 mm
✅ Thread M60×2
✅ Width approx 45 mm
✅ Lock Nut KM13
✅ Lock Washer MB13
✅ Fits tapered bore bearings like 1213K, 2213K, 1313K
✅ Used in SNL513 plummer block housings

💡 What is an adapter sleeve used for in bearing mounting for tapered bores?

A handy guide that explains how this part helps in common bearing installations.

• securely anchors tapered bore bearings on cylindrical shafts
• provides preload using KM13 lock nut and MB13 washer
• accommodates 60 mm shaft diameter with M60×2 threading
• works with standard plummer block housings like SNL513
