Female Rod End PHSB12L 3/4 Left hand Bearing

$61.99
SKU: Kit12666
UPC: 00193019210055
Item: PHSB12L Bearing
Type: Female Rod Ends
Thread Size: 3/4" UNF
Quantity: One Bearing
Dynamic Load Rating: 2,910 KGF

Female Rod End
Left Hand PHSB12L



Female Rod End PHSB12L, left hand Works with 3/4" Shafts, they are marked PHSB12L with 3/4" inner diameter, the internal thread size is 3/4", Here is the interchange designation in every brand:

  • Item: PHSB12L Bearing
  • Type: Female Rod Ends
  • Thread Size: 3/4" UNF
  • Quantity: One Bearing
  • Dynamic Load Rating: 2,910 KGF
  • Static Load Rating: 5,760 KGF


Dimensions (Inches)
d Thread S D B B1 d1 L L1 L2 W
3/4" 3/4"-16UNF 1-3/4" 45/64" 7/8" 0.978" 3-3/4" 2-7/8" 1-3/4" 1"
