Encoder Pulse Signal Splitter Distribution Module For TTL RS422 Two Channel Differential To HTL Board Built For Encoder Grating Ruler Systems Plug And Play Setup For Easy Reliable Signal Distribution
✔️ RS422/TTL input; two differential outputs + HTL; DC24V; 1 unit pack
This compact distribution module converts a single encoder pulse stream into two differential outputs and an HTL signal for PLCs, ideal for encoder rulers and grating systems. It offers plug-and-play setup for reliable signal distribution across displays, drivers, and controllers.
✅ Input channel: A+, A-, B+, B- (A, B open collector)
✅ Input signal: RS422 or TTL; options for 24V NPN/PNP PLCs must be specified
✅ Output channel: 1A+,1A-,1B+,1B-; 2A+,2A-,2B+,2B-; HTL signal: A,B
✅ Power: DC24V main; auxiliary DC5V@200mA for encoder/grating ruler
✅ Signal frequency: >1000KHZ
✅ Size: 8 cm L x 8.5 cm W x 4 cm H; Weight: 0.11 kg
✅ Customizable parameters available on request
