EMAGENE Air Operated Double Diaphragm Pump2 inch Inlet/Outlet Pneumatic Waste Oil Transfer Pump for Chemical DN50 172GPM Dual Diaphram Teflon by Aluminum alloy 120 PSI (2"PP+PTFE 175GPM)
Regular price
$731.88
Sale price$1,219.80you save $487.92
EMAGENE Air-Operated Double Diaphragm Pump - 2 Inch Inlet/Outlet, PTFE Diaphragm, 120 PSI, DN50, 172 GPM, Aluminum Alloy
✔️ Pneumatic double-diaphragm pump with PP body and PTFE diaphragm; 2-inch flange ports (DN50), max 120 psi, 172 GPM, 5 m suction; aluminum alloy build.
✅ Operation Type: Pneumatic
✅ Inlet/Outlet Ports: 2-inch DN50 flanges
✅ Main Material: Polypropylene body with PTFE diaphragm
✅ Interface: Inlet facing 1/2 inch NPT (12 mm)
✅ Average Air Consumption: 31.8 CFM
✅ Maximum Flow: 172 GPM (652 L/min)
✅ Maximum Head: 84 meters (275.6 ft)
✅ Maximum Suction Lift: 5 meters (16.4 ft)
✅ Maximum Pressure: 120 psi
✅ Self-Drying: 5 meters (10 ft)
✅ Self-Absorbing: 7 meters (23 ft)
✅ Material Compatibility: Waste oil, solvents, acetone, CNC coolant, diesel, kerosene, cement slurry
✅ Package Includes: 1 pump, 1 manual, 1 silencer
💡 What is an air-operated double diaphragm (AODD) pump used for in industrial fluid transfer applications? This handy pumping solution is designed to move a wide range of liquids in tough industrial settings. - Transfers waste oil, diesel, kerosene, solvents, and CNC coolant. - Handy for cement slurry, lime slurry, mud, and sewage in processing plants. - PTFE diaphragm and PP body provide chemical resistance and long service life. - Works with compressed air, enabling safe operation in hazardous areas and tight spaces. This handy transfer setup delivers reliable performance for demanding industrial tasks.
✔️ Pneumatic double-diaphragm pump with PP body and PTFE diaphragm; 2-inch flange ports (DN50), max 120 psi, 172 GPM, 5 m suction; aluminum alloy build.
EMAGENE's air-operated double diaphragm pump is designed for transferring viscous and corrosive liquids in demanding settings. The polypropylene body with a PTFE diaphragm offers excellent chemical resistance for waste oil, ethanol, gasoline, engine oil, diesel, cement slurry, sewage, CNC coolant, acetone, solvents, paints, and more. It's ideal across petroleum, metallurgy, mining, paint, water treatment, and automotive industries, delivering steady performance for both low- and some high-viscosity liquids. The 2-inch (DN50) inlet/outlet and 120 psi max pressure provide robust transfer capabilities with portable, safe operation.
✅ Diaphragm Pump Type: Double Diaphragm✅ Operation Type: Pneumatic
✅ Inlet/Outlet Ports: 2-inch DN50 flanges
✅ Main Material: Polypropylene body with PTFE diaphragm
✅ Interface: Inlet facing 1/2 inch NPT (12 mm)
✅ Average Air Consumption: 31.8 CFM
✅ Maximum Flow: 172 GPM (652 L/min)
✅ Maximum Head: 84 meters (275.6 ft)
✅ Maximum Suction Lift: 5 meters (16.4 ft)
✅ Maximum Pressure: 120 psi
✅ Self-Drying: 5 meters (10 ft)
✅ Self-Absorbing: 7 meters (23 ft)
✅ Material Compatibility: Waste oil, solvents, acetone, CNC coolant, diesel, kerosene, cement slurry
✅ Package Includes: 1 pump, 1 manual, 1 silencer
💡 What is an air-operated double diaphragm (AODD) pump used for in industrial fluid transfer applications? This handy pumping solution is designed to move a wide range of liquids in tough industrial settings. - Transfers waste oil, diesel, kerosene, solvents, and CNC coolant. - Handy for cement slurry, lime slurry, mud, and sewage in processing plants. - PTFE diaphragm and PP body provide chemical resistance and long service life. - Works with compressed air, enabling safe operation in hazardous areas and tight spaces. This handy transfer setup delivers reliable performance for demanding industrial tasks.
