DSM-25-270-CC-A-B Rotary Pneumatic Actuator With Double Acting, Rugged Industrial Grade, 0-246 Degrees Swivel Adjustment, 1.5-10 Bar Range, 10 Degrees Cushioning Angle, 25 mm Stroke, Dual End Pneumatic Shock Absorbers

Single-unit rotary pneumatic actuator with 25 mm stroke
✔️ Double-acting rotary pneumatic actuator, 0-246° swivel, 25 mm stroke

This rugged, industrial-grade rotary pneumatic actuator delivers controlled rotation for valve gates, dampers, and semi-rotary drives in automation lines. Built with a wrought aluminum alloy body and dual end shock absorbers, it’s designed for harsh environments where precise swivel control is needed.

✅ 0-246 degrees swivel adjustment range
✅ 1.5-10 bar operating pressure
✅ 10 degrees cushioning angle
✅ 25 mm stroke
✅ Double acting rotary actuator with dual end shock absorbers

💡 What is a rotary pneumatic actuator used for in automation systems?

These handy devices convert compressed air into rotational motion for valves, dampers, and limited-angle drives across manufacturing lines.

• Provides adjustable rotation for precise control in automation
• Operates on standard plant air pressure ranges (1.5-10 bar)
• Incorporates dual end shocks for smooth deceleration
• Built from rugged aluminum alloy for industrial duty
