DIY Digital Oscilloscope Module Kit With 2.4 Inch TFT Display For 0 To 200 KHz Range Hands On Education PCB Board For DSO138 Projects And Electronics Training Today
✔️ Comprehensive hands-on oscilloscope training kit for learning
This DIY Digital Oscilloscope Module is a compact educational tool designed for electronics labs and hobbyists. It lets students observe real-time signals and timing, making it ideal for classrooms, workshops, and self-study projects.
✅ Maximum real-time sampling rate: 1Msps
✅ Accuracy: 12Bit
✅ Sampling buffer depth: 1024 bytes
✅ Analog bandwidth: 0 - 200KHz
✅ Vertical Sensitivity: 10mV / Div - 5V / Div (1-2-5)
✅ Input impedance: 1MΩ
✅ Maximum input voltage: 50Vpp (1:1 probe), 400Vpp (10:1 probe)
✅ Coupling modes: DC / AC / GND
✅ Horizontal time base: 10μs / Div - 50s / Div (1-2-5)
✅ Trigger options: automatic, regular, one-shot; rising/falling edge
✅ Trigger level adjustable with pre-trigger capability
✅ HOLD function to freeze waveform
✅ Includes 1Hz / 3.3V square wave test signal source
✅ Pack: 1 piece assembled oscilloscope
💡 What is a digital oscilloscope module used for in electronics education?
This handy learning tool helps students visualize real-time signals and timing in circuits.
- digital oscilloscope module for education and hands-on learning
- real-time waveform visualization with trigger and sampling
- compact ARM Cortex-M3 based board with expansion potential
- supports data logging and secondary development projects
