Condenser HVAC Motor 1/6 HP, 1 Phase, 208/230V, 825 RPM Replacement With Included Run Capacitor For Central AC Systems, Built Tough, Easy Install, Reliable Performance

1/6 HP Condenser HVAC Motor - single unit (208/230V, 825 RPM)
✔️ 208/230V, 1 phase, 825 RPM, 1/6 HP, 5/370 run capacitor included

This condenser HVAC motor is a direct-drive replacement designed for outdoor condenser units in central air conditioning systems. It comes with a run capacitor to simplify installation and is built to endure demanding HVAC environments.

✅ 208/230V (1 phase)
✅ Frame size: 48
✅ Bearing type: Sleeve
✅ Drive type: Direct drive
✅ FLA at 208V (A): 1.0
✅ FLA at 230V (A): 1.0
✅ Frequency (Hz): 60
✅ High speed (RPM): 825
✅ HP: 1/6
✅ Input voltage (V): 208/230
✅ Keyed/Flat shaft length (inch): 4
✅ Motor body diameter (inch): 5-5/8
✅ Motor body length (inch): 4-5/16
✅ Mounting: Shell-band, shell-screw, thru-bolt
✅ Number of phases: 1
✅ Overall motor length (inch): 9-1/16
✅ Overall shaft length (inch): 4-1/2
✅ Rotation direction (OSE): Reversible
✅ Run capacitor (uF/V): 5/370
✅ Shaft diameter (inch): 1/2

💡 What is a condenser HVAC motor used for and how do I select a replacement?
This handy motor powers outdoor condenser fans in central AC systems.
- Match HP and voltage to your unit
- Verify shaft length and mounting fit to your condenser hardware
- Ensure run capacitor compatibility and proper electrical connections
- Choose a direct-drive design with reversible rotation for flexible mounting

✝️
