Beefy Torque Nema 17 Stepper Motor Bipolar 60Ncm With 1.65x1.65x2.36 Inch Body For Extruder And Precision Motion Control 1.8 Degree Step 2.1A 4 Wire Perfect For 3D Printers And CNC Machines
✔️ 60Ncm holding torque, 1.8 deg step, 1 pc single unit
This is a high torque bipolar stepper motor in the NEMA 17 form factor, built for extruders, 3D printers, and precision motion control on CNC setups. Its compact 42x42 mm frame with a 60 mm body length delivers strong performance in tight spaces while keeping wiring simple for reliable axis control.
✅ 60Ncm holding torque
✅ 1.8 deg step angle (200 steps/rev)
✅ Frame size 42 x 42 mm (1.65" x 1.65")
✅ Body length 60 mm (2.36")
✅ Shaft diameter 5 mm, length 24 mm
✅ D-cut length 15 mm
✅ Leads 4, lead length 500 mm
✅ Weight 500 g
✅ Connection: Black(A+), Green(A-), Red(B+), Blue(B-)
✅ Inductance: 3.1 mH +/- 20% (1KHz)
✅ Rated current/phase: 2.1 A
✅ Phase resistance: 1.7 ohm
💡 What is a high torque NEMA 17 stepper used for in motion control systems? This handy motor is commonly used in printers and CNC setups to drive precise axes.
- Long term torque stability improves axis accuracy
- Works with standard drivers and chopper controllers
- Compact 42x42 mm frame fits tight builds
- 1.8 degree steps deliver fine resolution for positioning
