Beefy 4KW 220V VFD Inverter For Spindle Motor CNC Router Engraving Milling Machine Pro Grade 5HP 3 Phase Output 18A Supports 1 Or 3 Phase Input Includes 2m Cable HY04D023B

4kW 220V VFD Inverter for Spindle Motors, 3-Phase 18A
✔️ Output 3-phase 220V +/-15%, 18A; Input 1-3 phase 220V; 0-400Hz

This compact drive powers CNC spindles in routers, engraving mills, and milling machines. It accepts both single and three-phase supply and delivers a smooth 3-phase 220V output for reliable speed control and torque management.

✅ HY04D023B
✅ Power 4KW (5HP) drive
✅ Input: AC 220V +/-15% 1 or 3 phase
✅ Output: 3 phase 220V +/-15% 18A
✅ Output frequency 0-400Hz; Input frequency 0-50/60 Hz
✅ Enclosure dims 152x175x220 mm (5.98x6.88x8.66 in)
✅ Weight 2.3 KG (5 LB)
✅ Includes 2 m extension cable
✅ Potentiometer speed control; PID closed-loop
✅ PLC function supports 16 speed control lines
✅ DC cooling fan; Mach3 function; RS-485 communication
✅ Protections overload, overvoltage, low voltage, overheating
✅ Applications: CNC Router, CNC milling, engraving, drilling systems
✅ Color: Black

💡 What is a VFD inverter used for in CNC machines? A handy device that lets you adjust spindle speed and torque for better control.

• handy for CNC router and milling machine spindle control
• 0-400 Hz output enables precise speed control
• works with 1 or 3 phase inputs for flexible setups

✝️
