Beefy 10 Ton Single Acting Alloy Steel Hydraulic Cylinder With One Port And 4.13 In Stroke For General Purpose Lifts With Tough Round Body And Spring Return Piston Rod Durable Enamel Finish Built For Rugged Use

Rugged 10-Ton Single-Act Cylinder with 4.13" Stroke
✔️ 10-ton alloy steel, round body, 4.13 in stroke, spring return

This single-acting hydraulic cylinder is designed for rugged lifting and pushing in general-use setups. It features a round alloy steel body with baked enamel finish for corrosion resistance and a single port with a spring-return piston rod for consistent movement in any orientation.

✅ Cylinder capacity: 10 tons (11.2 t max) for lifting or pushing
✅ Stroke: 4.13 in (105 mm) with integrated stop ring for controlled travel
✅ Bore: 1.69 in (43 mm); outside diameter: 2.25 in (57 mm)
✅ Weight: 7.2 lb (3.3 kg); alloy steel body with baked enamel finish
✅ Quick-connect CR-400 female coupler for CH-604 male coupler (sold separately)

💡 What is a hydraulic cylinder used for in industrial lifting and pressing?

These handy devices convert hydraulic pressure into linear force for lifting, pressing, and positioning loads in shops and plants.

• handy for lifting heavy loads in maintenance and assembly lines
• works with standard CR-400 and CH-604 couplers for quick connections
• spring-return design keeps motion controlled in tight spaces
