Beefed-Up Hydraulic Air Cooler For 200 L/min Oil Radiator With Heat Exchanger For Hydraulic Press Machines Delivers Fast Cooling, Withstand Up To 2 MPa, 24V Power, Smooth Shock Absorption
✔️ 200 L/min flow; 580x450x300 mm; 2 MPa max; 24 V, single unit
The AH1470T hydraulic air cooler is a compact oil radiator with a built‑in heat exchanger, designed to chill hydraulic oil quickly in presses and other industrial equipment. It fits tight spaces while delivering robust cooling up to 18,000 kcal/h and supports pressures up to 2 MPa.
✅ 200 L/min cooling flow to keep hydraulic oil temp in check
✅ Heat exchanger handles up to 2 MPa
✅ AC140W and DC120W fan options for flexible setup
✅ 8.3 m² cooling area for efficient heat transfer
✅ External dimensions 580x450x300 mm (22.8x17.7x11.8 in)
✅ Exhaust volume 3150 m³/h
✅ Connection RC1-1/4" thread for plumbing
✅ Color yellow
💡 What is a hydraulic air cooler used for in industrial machinery? This handy device helps keep hydraulic oil at the right temperature under heavy use. - Maintains oil viscosity and flow consistency - Reduces heat buildup and wear on seals and components - Improves system efficiency and life of hydraulic equipment - Simple installation in tight spaces with standard RC1-1/4" connections
