Nachi

90TAH10TDB Nachi Thrust Angular Contact Bearing 90x140x45 ABEC 7

No reviews
$1,337.88
SKU: Kit13567
Item: 90TAH10TDB Nachi Ball Bearing
Type: Nachi Angular Spindle Ball Bearing
Cage: Phenolic resin
Dimensions: 90mm x 140mm x 45mm/Metric
ID (inner diameter)/Bore: 90mm
90TAH10TDB Nachi Thrust Load Angular Contact Ball Bearing
30 degrees Contact Angle
Abec-7
Made in Japan


90TAH10TDB Nachi Thrust Load Angular Contact Ball Bearing, Ball Bearing is Super precision Angular with 30 degrees contact angle, bearing is ABEC-7 quality and made in Japan.

  • Item: 90TAH10TDB Nachi Ball Bearing
  • Type: Nachi Angular Spindle Ball Bearing
  • Cage: Phenolic resin
  • Dimensions: 90mm x 140mm x 45mm/Metric
  • ID (inner diameter)/Bore: 90mm
  • OD (outer diameter): 140mm
  • Width/Height/thickness: 45mm
  • Size: 90 x 140 x 45 mm
  • Quantity: One Bearing
  • Dynamic load rating Cr: 55,500 N
  • Static load rating Cor: 135,000 N
  • Limiting Speed:
    • Grease Lubrication: 6500 RPM
    • Oil Lubrication: 8200 RPM
  • Made in Japan
