Nachi

7219BMU Nachi Angular Contact Bearing Brass Cage C3 95x170x32 Bearings

$451.99
SKU: Kit9984
UPC: 00193019105931
Item: 7219BMU Nachi Ball Bearing
Type: Nachi Angular Ball Bearing
Radial Clearance: C3
Cage: Brass Cage
Dimensions: 95mm x 170mm x 32mm/Metric
7219BMU Nachi Angular Ball Bearing
40 Contact Angle
Brass Cage, Flush Ground
95mm x 170mm x 32mm
Made in Japan


7219BMU Nachi Angular Ball Bearings, bearing is 40 Contact Angle, Brass Cage and Flush Ground, Made in Japan, inner diameter is 95mm, outer diameter is 170mm and width is 32mm.

  • Item: 7219BMU Nachi Ball Bearing
  • Type: Nachi Angular Ball Bearing
  • Radial Clearance: C3
  • Cage: Brass Cage
  • Dimensions: 95mm x 170mm x 32mm/Metric
  • ID (inner diameter)/Bore: 95mm
  • OD (outer diameter):170mm
  • Width/Height/thickness: 32mm
  • Size: 95 x 170 x 32 mm
  • Quantity: One Bearing
  • Dynamic load rating Cr: 120,000 N
  • Static load rating Cor: 105,000 N
  • Limiting Speed:
    • Grease Lubrication: 3,000 RPM
    • Oil Lubrication: 4,000 RPM
  • Made in Japan

The raceways of both the inner and outer rings of this bearing type are made with a set contact angle. These bearings are non-separable. Since the balls are inserted utilizing counter-bore construction, a larger number of balls can be installed than in the case of Deep-groove ball bearings. Standard cage materials may be pressed steel, high-strength brass, or synthetic resin. Cage material is dependent on the bearing series and or service condition. Single-row Angular Contact ball bearings can sustain radial, axial or composite loads, however, any axial load must be in one direction. This bearing type is generally used in pairs to handle the induced load resulting from the internal axial force generated by the applied radial load. When mounting two single bearings in adjacent positions, NACHI provides these combination parts (pairs) with preadjusted clearance. Paired combination bearings are matched sets. Combination or paired bearings can be arranged BACK-TO-BACK (DB), FACE-TOFACE (DF), or in TANDEM (DT). DB or DF sets can sustain bidirectional axial loads.
