Nachi

7012CYDUP4BNLS Nachi Angular Contact Bearing 60x95x18 Abec-5 Japan

No reviews
$418.99
SKU: Kit10795
UPC: 00193019090954
Item: 7012CYDUP4BNLS Angular Ball Bearing
Type: Nachi Angular Ball Bearing
Dimensions: 60mm x 95mm x 18mm/Metric
Bearing Inner Diameter: 60mm
Bearing Outer Diameter: 95mm
7012CYDUP4BNLS Nachi Angular Abec-5 Ball Bearing
60mm x 95mm x 18mm
15 Contact Angle
Polyamide resin cage
Made in Japan


7012CYDUP4BNLS Nachi Angular Ball Bearings, 15 Contact Angle, Polyamide resin cage, Abec-5 Made in Japan, 7012CYDUP4BNLS inner diameter is 60mm, 7012CYDUP4BNLS outer diameter is 95mm, 7012CYDUP4BNLS width is 18mm.

  • Item: 7012CYDUP4BNLS Angular Ball Bearing
  • Type: Nachi Angular Ball Bearing
  • Dimensions: 60mm x 95mm x 18mm/Metric
  • Bearing Inner Diameter: 60mm
  • Bearing Outer Diameter: 95mm
  • Bearing Width: 18mm
  • Size: 60 x 95 x 18 mm
  • Quality: ABEC-5
  • Cage: Polyamide resin cage
  • Basic Dynamic Load Cr (KN): 35.5
  • Made in Japan
  • Quantity: One Bearing

d D B r r1
60mm 95mm 18mm 1.1 0.6

* The bearing type has raceways in both the inner and outer rings with a specific contact angle.
* These bearings cannot be separated.
* They can accommodate a larger number of balls compared to deep-groove ball bearings due to their counter-bore construction.
* The cage material can be pressed steel, high-strength brass, or synthetic resin, depending on the bearing series and service condition.
* Single-row angular contact ball bearings can handle radial, axial, or combined loads, but axial loads must be in one direction.
* These bearings are typically used in pairs to handle the induced load caused by the internal axial force from the applied radial load.
* NACHI provides preadjusted clearance for paired bearings when mounting two single bearings in adjacent positions.
* Paired combination bearings are matched sets.
* Combination bearings can be arranged in three configurations: back-to-back (DB), face-to-face (DF), or tandem (DT).
* DB or DF sets can handle bidirectional axial loads.
