Nachi

6916ZZ Nachi Bearing Shielded 80x110x16 Japan Large

$289.99
SKU: Kit14439
UPC: 00193019099117
Item: 6916ZZ Nachi Ball Bearing
Type: Nachi Deep groove Ball Bearing
Closures: Double shielded with Metal shields Z/ZZ/2Z
Dimensions: 80mm x 110mm x 16mm/Metric
ID (inner diameter)/Bore: 80mm
6916ZZ Nachi Bearing
80mm x 110mm x 16mm
Made in Japan


6916ZZ Nachi Bearing, the 6916ZZ inner diameter is 80mm, the 6916ZZ outer diameter is 110mm, 6916ZZ width is 16mm.

  • Item: 6916ZZ Nachi Ball Bearing
  • Type: Nachi Deep groove Ball Bearing
  • Closures: Double shielded with Metal shields Z/ZZ/2Z
  • Dimensions: 80mm x 110mm x 16mm/Metric
  • ID (inner diameter)/Bore: 80mm
  • OD (outer diameter): 110mm
  • Width/Height/thickness: 16mm
  • Size: 80 x 110 x 16 mm
  • Quantity: One Bearing
  • Dynamic load rating Cr: 27,600 N
  • Static load rating Cor: 25,300 N
  • Limiting Speed:
    • Grease Lubrication: 5,700 RPM
  • Made in Japan

Advanced Shield Design Provides
Superior Protection and Quiet Operation

The shield design was optimized using dynamic analysis modeling techniques.The design profile and plate thickness provides rigidity that helps quiet operation as well asretain grease and protect against intrusion of major contamination.

  • Superior in Sealing Out Contamination
  • Superb Grease Retention
  • Quiet Operation
    The Best Components Yield the Greatest Bearing Performance
    Rings and balls made of select material have superbly controlled accuracy such as roundness, contour,surface finish, and hardness to provide quieter operation, reduced vibration levels, and long life.Rivet-type pressed steel cages for strength and durability.High-performance grease for long life and low noise.
