2D LiDAR Sensor With 360 Degree Scanning And 8m Range, 2300 Hz Refresh Rate, Triangulation Based Scanning For Robot Obstacle Avoidance And Auto Navigation, High Precision Mapping And Smooth Autopilot Routing

2D LiDAR Sensor with 360° Scan and 8m Range for Robotics
✔️ Triangulation-based LD14P 1-unit kit with 360° FOV, 8m range, 6Hz scan

LD14P is a triangulation LiDAR sensor that detects the environment around a robot in a full 360-degree field of view. It's ideal for obstacle avoidance and auto navigation, giving reliable mapping and path planning for mobile robots and automation systems.

✅ Distance measurement range: 0.1-8 m (white target, 80% reflectivity)
✅ Black target range: 0.1-6 m (4% reflectivity)
✅ Scanning frequency: 2-8 Hz external controllable; default 6 Hz
✅ Field of view: 360°; Pitch 0° to 1.0°; Angular resolution 0.54°
✅ Start-up time: ≤3.5 s; typical 3 s
✅ Ambient light tolerance: 80000 Lux; anti-glare filtering

💡 What is a 2D LiDAR sensor used for in robotics and automation? A handy overview of its role in obstacle detection and mapping. - 360° scanning for full environment awareness - 8 m range enables early obstacle detection - Compact, dust-resistant design easy to mount - Dense point clouds improve navigation and mapping accuracy
