14-Bit High-Precision Magnetic Encoder Module For Accurate Rotary Position Sensing In Motion Control And Robotics, Non-Contact Magnetic Induction Sensor Delivers Wear-Free Long-Term Stability And Snappy Feedback

14-Bit Magnetic Encoder Module for Precise Rotary Feedback
✔️ Single-unit pack; 14-bit absolute angle, I2C/SSI, 3.3-5V, -40-125°C

The 14-bit high-precision magnetic encoder module delivers absolute angular position sensing using non-contact magnetic induction. It's designed for motion control, robotics, CNC equipment, and automation systems, offering wear-free operation even in harsh environments. Color: Black.

✅ 14-bit resolution for angular position
✅ Non-contact magnetic sensing for wear-free operation
✅ Absolute angle measurement 0°-360°
✅ Interfaces: I2C/SSI; Analog/PWM options
✅ Operating voltage 3.3-5.0V
✅ Operating temperature -40°C to 125°C
✅ Latency as low as 5µs; up to 55,000 RPM
✅ Incremental ABZ output 1-1024 lines
✅ 12-bit PWM or 12-bit DAC output
✅ Dedicated press detection output
✅ Built-in EEPROM with >1000 reprogramming cycles

💡 What is a magnetic encoder module used for in motion control and robotics?

It provides precise angular feedback for closed-loop control systems.

- 14-bit angle data via I2C/SSI - Analog or PWM output options for flexible integration - Wide operating range and rugged performance for industrial environments ✝️
