Nachi

120TAH10TDB Nachi Thrust Angular Contact Bearing 120x180x54 ABEC 7

No reviews
$2,583.88
SKU: Kit13570
Item: 120TAH10TDB Nachi Ball Bearing
Type: Nachi Angular Spindle Ball Bearing
Cage: Phenolic resin
Dimensions: 120mm x 180mm x 54mm/Metric
ID (inner diameter)/Bore: 120mm
120TAH10TDB Nachi Thrust Load Angular Contact Ball Bearing
30 degrees Contact Angle
Abec-7
Made in Japan


120TAH10TDB Nachi Thrust Load Angular Contact Ball Bearing, Ball Bearing is Super precision Angular with 30 degrees contact angle, bearing is ABEC-7 quality and made in Japan.

  • Item: 120TAH10TDB Nachi Ball Bearing
  • Type: Nachi Angular Spindle Ball Bearing
  • Cage: Phenolic resin
  • Dimensions: 120mm x 180mm x 54mm/Metric
  • ID (inner diameter)/Bore: 120mm
  • OD (outer diameter): 180mm
  • Width/Height/thickness: 54mm
  • Size: 120 x 180 x 54 mm
  • Quantity: One Bearing
  • Dynamic load rating Cr: 29,800 N
  • Static load rating Cor: 75,000 N
  • Limiting Speed:
    • Grease Lubrication: 5,000 RPM
    • Oil Lubrication: 6,300 RPM
  • Made in Japan
