1099 12 And 24 Volt Gate Receiver With 10 DIP On Off Type Code Switch And F Connector Antenna For Garage Door Opener 300 MHz And 310 MHz Single Channel Plug And Play Setup For 109950 Linear MCS109950 Systems Reliable Range

12/24V Gate Receiver with 10-DIP switch for 300/310MHz
✔️ Single unit, plug-and-play, 12/24V auto-sensing, 300/310MHz

The single-channel gate receiver handles 12/24V DC or AC power and works on 300MHz or 310MHz frequencies. An F-connector antenna lets you position the antenna for best range, especially when the unit is inside a metal enclosure. Suitable for garage door openers and gate controllers.

✅ Power: 12-30 V AC or 10.5-30 V DC
✅ Frequency: 300MHz or 310MHz jumper selectable
✅ Codes: 1,024 codes (set by 10 DIP switches)
✅ Contacts: One N/O contact rated 1 A at 30 V
✅ Antenna: F-connector antenna for extended range
✅ Dimensions: 5.5 x 1.5 x 3.625 inches

💡 What is a 12/24V gate receiver with 10 DIP switches and 300/310MHz used for?
It's a handy, single-channel receiver for gate and garage door systems, enabling remote control from compatible remotes.
- Handy for gate control in residential and commercial setups
- Works with a wide range of remotes operating in the 300/310MHz bands
- Supports 12/24V auto-sensing for flexible wiring
- Uses 10 DIP switches to set 1,024 unique codes

✝️
