1000mm Draw Wire Linear Displacement Sensor With Incremental Encoder CESI S1000 Pushpull Output, 0.1mm Per Pulse Resolution, 1m Shielded Cable, 5V 12V 24V DC Supply, Max Speed 6 Meters Per Second, 16kg Max Force

1000mm Draw-Wire Linear Sensor with Encoder 1 unit
✔️ 0.1mm/pulse, 6 m/s max, 16 kg max, 1m shielded cable, 5/12/24V

The 1000mm draw-wire displacement sensor uses a robust encoder to measure linear position with high accuracy across a 1000 mm travel. It's commonly used in automation, robotics, CNC machines, and test rigs where reliable position feedback is critical.

✅ 1000 mm travel range
✅ 0.1 mm per pulse resolution
✅ 1 m shielded cable output
✅ Push-pull ABZ incremental output
✅ DC supply options: 5V/12V/24V

💡 What is a draw-wire displacement sensor used for in precision measurement? This handy device provides reliable position feedback for linear motion systems in automation, robotics, CNC machines, and testing rigs.

• Precise linear position sensing for control systems
• Easy integration with push-pull ABZ outputs
• Works with common 5/12/24 V DC supplies and shielded cables
• 1000 mm travel with 0.1 mm per pulse resolution
