22209MKC3W33 Spherical Roller Bearing 45x85x23 with Tapered Bore

SKU: 22209MKC3W33
UPC: 00193019142363

Spherical Roller Bearing
with Tapered Bore and Bronze cage

22209MKC3W33 Spherical Roller Bearing,with Tapered Bore and Bronze cage, the 22209MKC3W33 inner diameter is 45mm, the 22209MKC3W33 outer diameter is 85mm and the 22209MKC3W33 width is 23mm with a C3 clearance.

  • Item: 22209MKC3W33 Roller Bearing
  • Type: Spherical Roller Bearing with Tapered Bore
  • Cage: Bronze Cage with C3 clearance
  • Dimensions: 45mm x 85mm x 23mm/Metric
  • ID (inner diameter)/Bore: 45mm
  • OD (outer diameter): 85mm
  • Width/Height/thickness: 23mm
  • Size: 45x85x23 mm
  • Quantity: One Bearing
  • Dynamic load rating Cr: 133,000 N
  • Static load rating Cor: 110,000 N
  • Limiting Speed:
    • Grease Lubrication: 6,000 RPM
    • Oil Lubrication: 7,500 RPM

Spherical Roller Bearings are particularly suitable for applications where misalignment can arise from error in mounting or from shaft deflection. Spherical Roller Bearings are manufactured in a number of design and material configurations depending on the type of application and size of the bearing. Spherical Bearings have two designs, regular spherical roller bearings and spherical roller thrust bearings.
